Database Basic Notes

Basic Concepts

Feature

  • Massive
  • Persistent
  • Safe
  • Multi-user
  • Convenient
  • Efficient
  • Reliable

Common Words

  • create/drop(from)/insert into/delete from/update
  • restricts
  • sub-queries
  • views(shorthand for queries)
  • left/right join on ...
  • primary/foreign key
  • references

(id, name, birth, major, grade) is not normalized, because grade is not relevant to student id (id, name, birth) + (id, major, grade) is normalized (name, os, lang) is not normalized, because os isn't relevant to lang (name, os) + (name, lang) is normalized Data-intensive applications may not use DBMS/Query Language at all e.g Hadoop, all operations on data stores in files

Data Format

XML

  • single root element
  • matched tags with proper nesting
  • unique attributes within elements

DTD

Document Type Definition:

  • similar grammar to regular expression(*?)
  • ID/IDRef should be unique
  • CDATA: character data
  • (#PCDATA): parsed character data (plain text between tags)
<?xml version="1.0" encoding="utf-8"?>

<!DOCTYPE Bookstore [
<!ELEMENT Bookstore (Book)*>
<!ELEMENT Book (Title, Authors, Remark?)>
<!ATTLIST Book ISBN ID #REQUIRED
Price CDATA #REQUIRED
Authors IDREFS #REQUIRED>
<!ELEMENT Title (#PCDATA)>
<!ELEMENT Remark (#PCDATA | BookRef)*>
<!ELEMENT BookRef EMPTY>
<!ATTLIST BookRef book IDREF #REQUIRED>
<!ELEMENT Authors (Author)*>
<!ELEMENT Author (First_Name, Last_Name)>
<!ATTLIST Author Ident ID #REQUIRED>
<!ELEMENT First_Name (#PCDATA)>
<!ELEMENT Last_Name (#PCDATA)>
]>

<Bookstore>
<Book ISBN="ISBN-0-23-23333-233" Price="233" Authors="Sabertazimi">
<Title>Kind of sword</Title>
<Authors>
<Author Ident="Sabertazimi">
<First_Name>Yilong</First_Name>
<Last_Name>Liu</Last_Name>
</Author>
</Authors>
</Book>
</Bookstore>

Tools: XML Copy Editor, XML Linter:

xmllint --valid --noout Bookstore.xml

XSD

XML Schema Definition:

xmllint -schema Bookstore.xsd -noout Bookstore.xml

JSON

JavaScript Object Notation:

  • serializing data objects in files
  • human-readable data
  • semi-structured data
  • number/boolean/string/array/object(empty or key-value pair) recursive constructs

Relational Algebra

Operators

  • select operator σ(sigma): σ(sID < 100 ^ sAge > 20)Table_Name set constraints
  • project operator π(pi) : π(sID, GPA)Table_Name select certain columns
  • cross-product operator x: Table1 x Table2, m tuples(rows) x n tuples(rows) => m*n tuples(rows)
  • natural join operator ∞: σ(E1.A1 = E2.A1 ^ E1.A2 = E2.A2 ...) (E1 x E2)
  • theta join operator ∞(condition): σ(condition) (E1 x E2), call condition as ϴ
  • difference operator -: matching schemas => change rows/tuples
  • union/intersection operator ∪ / ∩: matching schemas => change rows/tuples
  • rename operator ρ: change schemas(attributes name), different schemas <=> same schemas (union/intersection/self-join)
  • assign statement :=
  • tree notation
π(sID, GPA) (σ(sID < 100 ^ GPA > 3.7) Student)

Higher-Level Database Design Models

Higher-Level Database Design Models -Translator-> Relational implemented by RDBMS

UML

Unified Modeling Language: PlantUML

Classes

for data modeling:

  • add PK(primary key)
  • drop methods
-----------
| student |
|---------|
|sID PK |
|sName |
|GPA |
|---------|
|<methods>|
-----------

Associations

relationships between objects of 2 classes):

  • one to one: 1..1 --- 1..1.
  • many to one: * --- 1..1
  • one to many: 1..1 --- *.
  • many to many: * --- *.
-----------                   ---------
| student | |college|
|---------| | |
|sID PK |x..y Apply m..n| |
|sName |-------------------| |
|GPA | | |
|---------| | |
|<methods>| | |
----------- ---------

Associations Classes

  • classes store information of relationship edge between 2 data classes
  • unnecessary if 0..1 or 1..1
c1 * --- 1..1 c2
information of relationship edge can stored in c1
owing to every object of c1 only associated with 1 object of c2

Subclasses

children classes

Composition and Aggregation

Entity Relationship Model

SQL

  • select ... from ... where
  • insert into ... ...
  • delete from ... where ...
  • update ... set ... = ... where ...
DROP VIEW IF EXISTS Standings;
DROP VIEW IF EXISTS Count;
DROP VIEW IF EXISTS Wins;
DROP TABLE IF EXISTS Matches;
DROP TABLE IF EXISTS Players;

-- Players Table
CREATE TABLE Players (
id SERIAL primary key,
name varchar(255)
);

-- Matches Table
CREATE TABLE Matches (
id SERIAL primary key,
player int references Players(id),
opponent int references Players(id),
result int
);

-- Wins View shows number of wins for each Player
CREATE VIEW Wins AS
SELECT Players.id, COUNT(Matches.opponent) AS n
FROM Players
LEFT JOIN (SELECT * FROM Matches WHERE result>0) as Matches
ON Players.id = Matches.player
GROUP BY Players.id;

-- Count View shows number of matches for each Player
CREATE VIEW Count AS
SELECT Players.id, Count(Matches.opponent) AS n
FROM Players
LEFT JOIN Matches
ON Players.id = Matches.player
GROUP BY Players.id;

-- Standings View shows number of wins and matches for each Player
CREATE VIEW Standings AS
SELECT Players.id,Players.name,Wins.n as wins,Count.n as matches
FROM Players,Count,Wins
WHERE Players.id = Wins.id and Wins.id = Count.id;

Relational Design

Decomposition

  • start with mega-relations: including all attributes
  • decompose into smaller relations(BCNF/4NF)

functional dependencies

  • A -> B => 1-1/n-1 mapping
  • key sets: closure of sets contains all attributes

assuming relation R(A, B, C, D, ..., G) and closure of A, B {A, B} + A->C->D, B->E->F, F->G => {A, B}+ = {A, B, C, ..., G} then, {A, B} is a key if there no exists such closure, then treat all-attributes as a key

BCNF

boyce-codd normal form:

  • for each A -> B having A is super key && B isn't key
  • not exists A -> B -> C
  • here's the algorithm:
/*
* @brief fixed point algorithm just like most algorithms from compiler
*
* by decomposing to transform non-key dependent attributes to key dependent attributes
*/

compute FDs for R
compute key for R using its FDs

while (there is relation R' aren't in BCNF) {
pick any R' with A -> B that violates BCNF (A is not its key)
decompose R' into R1(A, B) and R2(A, rest)
compute FDs for R1 and R2
compute keys for R1 and R2 using their FDs
}

Multi Valued Dependencies

  • A -> B && rest attributes => A ->> B.
  • A ->> B (1-n mapping), A ->> C (1-n mapping), no B -> C/C ->> B, B * C redundant tuples/rows.
  • A ->>B && A ->>C => A ->> B∩C.
  • A ->>B && B ->>C => A ->> C-B.

4NF

Forth normal form:

  • if A ->> B then A is key && B isn't key
  • here's the algorithm:
/*
* @brief fixed point algorithm just like most algorithms from compiler
*
* by decomposing to transform non-key dependent attributes to key dependent attributes
*/

compute FDs and MVDs for R
compute key for R using its FDs

while (there is relation R' aren't in 4NF) {
pick any R' with A ->> B that violates 4NF(A is not its key)
decompose R' into R1(A, B) and R2(A, rest)
compute FDs and MVDs for R1 and R2
compute keys for R1 and R2 using their FDs
}

Normalized Design

  • every row has the same number of columns
  • every row has a unique key(PRIMARY KEY)
  • everything in a row is all relevant to unique key
  • everything in a row is all relevant to each other

Indexes

  • primary mechanism to improve performance of database
  • persist data structures stored in database (hash tables/B trees/B+ trees)
  • trade off: scale of database and workload(query/update rate) as input of physical design advisors
CREATE INDEX IndexName on T(A)
CREATE INDEX IndexName on T(A1, A2, ..., An)
CREATE UNIQUE INDEX IndexName on T(A)
DROP INDEX IndexName

Transactions

  • a sequence of one/more SQL operations treated as a unit
  • target: concurrency and failures recovery

Transaction Standard

  • all or nothing(atomicity)
  • transaction begins automatically on first SQL statement
  • on "commit": old transaction ends, new one begins
  • on session termination: current transaction ends
  • "AutoCommit" turns each statement into transaction

ACID Properties

  • Atomicity(Logging)
  • Consistency
  • Isolation: guarantee serializability(Locking)
  • Durability(Logging)

Isolation Level

weaker isolation level: read uncommitted < read committed < repeatable read < serializable

  • increased concurrency + decreased overhead = increased performance
  • weaker consistency guarantees
  • some system default: repeatable read
SET TRANSACTION READ ONLY;
SET TRANSACTION ISOLATION LEVEL REPEATABLE READ;

Integrity Constraints

CREATE TABLE TableName (
... PRIMARY KEY,
... UNIQUE,
... CHECK (Condition),
... references TableName(ForeignKey),
... references TableName(ForeignKey) ON DELETE/UPDATE RESTRICT/SET NULL/CASCADE,
... ,
PRIMARY KEY (Attr1, Attr2, ...),
UNIQUE (Attr1, Attr2, ...),
CHECK (Condition),
FOREIGN KEY (Attr1, Attr2, ...) references
TableName(Bttr1, Bttr2, ...) [ ON ... (default RESTRICT) ]
);

CREATE ASSERTION AssertionName
CHECK (Condition);

Triggers (DBMS Level Constraints)

CREATE TRIGGER TriggerName
BEFORE|AFTER|INSTEAD OF Events(INSERT/UPDATE OF/DELETE ON TableName)
[ referencing-variables ]
[ FOR EACH ROW ]
WHEN ( Condition )
[ BEGIN ]
Action
[ END ];

CREATE TRIGGER Cascade
After DELETE ON S
REFERENCING OLD ROW AS O
FOR EACH ROW
DELETE FROM R WHERE A = O.B (R.A = S.B)

CREATE TRIGGER Cascade
After DELETE ON S
REFERENCING OLD TABLE AS OT
DELETE FROM R WHERE A IN (SELECT B FROM BT)

Views

  • logical layer: hiding data from users
  • modularity and reuse of query
VIEW ViewName = VIEWQUERY (R1, R2, ..., Rn)

CREATE VIEW ViewName (T1, T2, ..., Tn) AS
< Query >

Modifications on Views

owing to views are logical layer, it's senseless to modify data on views

Implements Modification with Triggers

CREATE TRIGGER TriggerName
INSTEAD OF DELETE/UPDATE OF/INSERT ON ViewName
[ referencing-variables ]
[ FOR EACH ROW ]
WHEN ( Condition )
[ BEGIN ]
Action
[ END ];

SQL Standard - Updatable Views

  • SELECT (no DISTINCT) on single table T
  • no GROUP BY/HAVING or Aggregation
  • attributes can't be NULL/default values
  • sub-queries cant' refer to table T
CREATE VIEW
...
WITH CHECK OPTION;

MongoDB Basic Notes

MongoDB Set Up

MongoDB Installation

sudo apt-key adv --keyserver hkp://keyserver.ubuntu.com:80 --recv EA312927
echo "deb http://repo.mongodb.org/apt/ubuntu trusty/mongodb-org/3.2 multiverse"
\ | sudo tee /etc/apt/sources.list.d/mongodb-org-3.2.list
sudo apt-get update
sudo apt-get install -y mongodb-org mongodb-org-server
\ mongodb-org-shell mongodb-org-mongos mongodb-org-tools

MongoDB Not Upgrade

echo "mongodb-org hold" | sudo dpkg --set-selections
echo "mongodb-org-server hold" | sudo dpkg --set-selections
echo "mongodb-org-shell hold" | sudo dpkg --set-selections
echo "mongodb-org-mongos hold" | sudo dpkg --set-selections
echo "mongodb-org-tools hold" | sudo dpkg --set-selections

MongoDB Control

sudo service mongod start
sudo service mongod stop
sudo service mongod restart

MongoDB Uninstall

sudo service mongod stop
sudo apt-get purge mongodb-org*
sudo rm -r /var/log/mongodb
sudo rm -r /var/lib/mongodb

Shell Instruction

create and drop

create
use test
show dbs
drop
use dbToDrop
db.dropDatabase()

query

db.collection.find().pretty()

insert

db.collection.insert();

information

database
db.getName()
db.stats()
db.version()
db.getMongo()
collection
db.getCollectionNames()
db.printCollectionStats()
